Audix D 2 Trio

D2 Trio

3-piece drum microphone package

OVERVIEW

The Audix D2 Trio is everything you need for miking your toms, all in one convenient package. The tailored frequency response of the D2 drum microphone gives you all the punch, clarity, and warmth needed for percussion without being muddy or boomy. The proprietary VLMTM (Very Low Mass) capsule technology provides superior transient response and more accurately captures every detail of your music. The included DVICE mounts let you squeeze these microphones into tight places eliminating the need for bulky microphone stands.

Designed, machined, assembled, and tested by Audix in the USA.

OPERATION AND MAINTENANCE

The D2 is a low impedance microphone and should be plugged into a ‘mic level’ input of your console, mixer, or recording device. Please note that your microphone does not require phantom power and will not be affected in any way by phantom power should it be running simultaneously while the microphone is in operation. Avoid plugging or unplugging the microphone from the PA system unless the channel is muted or the volume of the system turned down. Failure to do so may result in a loud ‘popping’ noise which could seriously damage the speakers in the PA system provided when not in use. Moisture of any kind can adversely effect the sound and performance of your microphone.

USER TIPS

The D2 has an extremely tight hypercardioid pick-up pattern in order to help eliminate sound from other instruments on stage from ‘bleeding’ into the microphone. For this reason, the D2 is exceptionally effective in capturing the sound of each component of a drum or percussion kit.

As a general rule, the bottom of the D2 grill should be 1-2 inches above the head of the drum and pointed towards the center. For more ‘ring’ pull the mic back towards the rim. For less ring and more overtones, position the mic 1-2 inches inside the ring. For more attack, place the mic very close to the head and for more overtones and decay move the mic further away from the head.

Further miking techniques may be found at www.audixusa.com.
